26 MA_VEB100-1-2-2W-4-5_A3-1_190627_en.doc

Fig. 5

Kl. VEB100-5

Kl. VEB100-4

3.1.7 Replacing the folder

Loosen screw (1) (Fig. 4), mount and tighten the new folder.

Realize settings as described in “3.1.6 Setting the folder”.
