Screw connections
It is vital that all bolted connections on the
S-pedelec have the correct torque in order to en-
sure that they are secure. Too much torque can
damage the screw, nut or component. Always use
a torque spanner to tighten screw joints. You are
not able to correctly tighten these bolted connec-
tions without this specialist tool!
If a component specifies a torque for its bolt-
ed connections, then this should be strictly ad-
hered to. Please read the instructions provided by
the manufacturer, which often list the correct
mounting torques.
When a screw connection was treated with
threadlocking adhesive (screw adhesive, e.g. Loc-
tite), threadlocking adhesive must be used when-
ever this connection is opened, loosened or re-
tightened.
Component ST2 S ST2 ST1X Torque
Clamping handles (Ergon GS1-L) – handlebar
* *
- 5 Nm
Clamping handles (Velo) – handlebar - -
*
2 Nm
Clamping brake lever (Tektro) – handlebar - -
*
5 – 7 Nm
Clamping brake lever (Magura) – handlebar
* *
- 4 Nm
Clamping gear lever (Shimano SLX) – handlebar -
* *
3 Nm
Clamping gear lever (Shimano Alfine Di2) – handlebar
*
- - 5 – 7 Nm
Clamping stem - handlebar
* * *
6 Nm
Clamping stem – steer tube (carbon)
* *
- 5 Nm
Clamping stem – steer tube (aluminum) - -
*
5 – 6 Nm
Clamping headset top cap – steer tube
* *
- 2,5 Nm
Clamping saddle underframe
* *
- 13 – 15 Nm
Clamping saddle angle
* *
- 10 – 12 Nm
Clamping seat rails and seat angle - -
*
12 – 15 Nm
Clamping saddle clamp – frame – saddle post
* * *
10 Nm
Front axle
* * *
20 Nm
Rear axle
* * *
20 Nm
Brake disk (6-hole, Tektro) -
* *
6 – 8 Nm
Brake disk (6-hole, Magura)
* *
- 4 Nm
Brake disk (4-hole, Syno Drive & CYRO Drive HR-hub)
* * *
7 Nm
