13 Revision: March 2018
Fold the frame by first folding the footplates into the upright position (3) and then pulling
the seat evenly upwards using both hands to hold the middle of the seat at the front and
rear (4).
6.3 Removing the drive wheels
The drive wheels are fitted with a quick-release axle. The wheels can be removed and
refitted without tools. To remove the wheels press the locking button (1) and remove the
drive wheel from the frame.
Press the locking button to attach the axle to its mounting. Release the locking button to fix
the axle in place. Ensure that the locking button springs back into its initial position.
CAUTION!
Every time you refit the drive wheels, check to make sure that the axle is
securely fitted back in place by trying to remove the wheel without pressing
the locking button. The wheel should not come away from the frame.
