15 Revision: March 2018
Caution!
Do not stand on the footrests as they may break, increasing the risk of injury.
The wheelchair could also tip over.
6.5 Removing the footrests
The footrests can be completely removed from the wheelchair by pulling the plastic clip with
its retaining pin (1) horizontally out of the tube. The whole of the footrest can then be pulled
up and out of the footrest mounting. When refitting the footrests ensure that the hole for
the locking pin in the footrest is aligned with the hole in the frame.
6.6 Using and removing the anti-tip wheels
The anti-tip wheels are designed to prevent the wheelchair from tipping over backwards.
They can be removed from the wheelchair for transportation purposes by pressing on the
locking button (1) and pulling the wheels out of the frame tubing.
Caution!
The locking buttons should protrude out of their apertures(1). This must be
checked carefully after each adjustment and especially when the anti-tip
wheels have been temporarily removed and then refitted.
