Introduction
5
Product Description/Intended Use / Location and Function of Parts and Controls
EN
Introduction
Product Description/
Intended Use
The SDP1000 Stryker Digital Color Printer, REF
0240080230, is a dye sublimation thermal transfer printer
providing high quality and high resolution printing of
Stryker Digital Capture Device image data on A4 or letter
size paper in full color (256 gradations process and 16.7
million colors).
It prints images by pressing a thermal head, heated
according to the input image data, against a dedicated ink
ribbon coated with sublimation ink, transferring the ink
onto special thermal printing paper.
This device is intended for use in medical environments,
such as clinics, examination rooms, and operating rooms.
Indications/Contraindications
The Stryker Printer is a medical accessory, that when used
with the SDC systems, is intended to be used to record
operative procedures.
There are no known contraindications.
System Configuration
Location and Function of
Parts and Controls
Front
A 1 On/standby switch/indicator
When this switch is pressed, the indicator lights, and
the printer enters the ready state. When it is pressed
again, the indicator flashes and then goes out, and the
printer enters the standby state.
B Paper cover
Printouts stack here.
C Paper outlet
Printouts are ejected here.
D Vent openings
E Media tray (page 10)
The ink ribbon and paper are loaded here.
F Stopper (page 14)
Flip this stopper up in order to prevent the ejected
printouts from falling.
SDP1000 Stryker Digital Color Printer
Stryker Digital
Capture Device
USB cable
To Next Page
