Frequency adjustment：
Enter testing mode：Hold COLOR to power on，adjust FREQ for rough adjust，CLAR external spindle for fine adjust，FUNC、
COLOR key are used to switch between testing items.
VCO frequency adjustment： Testing point TP513， FM mode，CLAR inner spindle in middle position（an Obviously fixed-point
can be find in middle point），before adjustment, power on radio in USB mode for 2-5 minutes.
Choose FRQ 320：adjust L807，frequency 38.695MHZ±10HZ，background noise < 40HZ
Choose F05 XXX：adjust frequency 38.695MHZ±10HZ，background noise < 40HZ
Turn clockwise and anti clockwise to the end and test. the fluctuation need 500±100Hz, switch the knob
to middle position after testing.
Choose F15 XXX： frequency need 38.695MHZ±10HZ，background noise < 40HZ
Turn clockwise and anti clockwise to the end and test. the fluctuation need 1500±200Hz, switch the knob
to middle position after testing.
Choose F25 XXX： frequency need 38.695MHZ±10HZ，background noise < 40HZ
Turn clockwise and anti clockwise to the end and test. the fluctuation need 2500±300Hz, switch the knob
to middle position after testing.
Note：FRQ 320 data can not adjusted，if the frequency fluctuation is <100HZ，you can adjust ±70>
After testing FO5、F15、F25 frequency fluctuation，be sure to turn the CLAR inner spindle in middle position.
BFO frequency adjustment：Enter testing mode，choose BFXX display，testing point TP301
Choose FM mode，frequency need 10.695MHZ±10HZ，background noise < 40HZ
Choose USB mode，frequency need 10.6975MHZ±10HZ，background noise < 40HZ
Choose LSB mode，frequency need 10.6925MHZ±10HZ，background noise < 40HZ
AFF frequency adjustment：Enter testing mode，choose AFFXXX display，testing point TP514
Choose FM mode，frequency need 10.240MHZ±40HZ，background noise < 40HZ
Note1：During alignment，choose the minimum deviated frequency, do well adjust and warm up the testing machine.
If the deviation not meet standard, revise the C582 5P capacitance，Capacitance between 1-6P，if still not OK，check
other index.
Note2：T he final frequency are composed by BFO and VCO frequency, when the testing transmitting frequency is error, it is
necessary to recheck both frequency. Due to high requirement on accuracy, do adjust this 2 frequency after the
temperature turn normal if any soldering work near the 10.24MHZ, and 10.6975 MHz component. Y800, Y501,
Y500 must grounded, the housing of L807 and Y800 shall be touched. After finish above alignment, be sure to
install the shield over the 2 VCO to ensure rest alignment
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
TX testing
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
Note：Voltage 13.8V，testing machine with filter＜20HZ HPF and 15KHZ LPF，DE－EMPHASIS is OFF。Clockwise turning
is for increase power, anti clockwise turning is for reduce low. The power switch only work for AM,FM mode.
If the power is too big, connect a Attenuator with testing machine.
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
TX Voltage：When the FM power is over 50W 时（current around 9A）， The voltage is 13V
Switch location： All the 5 Rocker Switch fix in middle position，CLAR inner spindle fix in middle point ，MIC GAIN to
maximum
