Stryker SR-955HP - AF sensitivity (AM); HI-CUT function; ANL function; RF GAIN function

AF sensitivity：choose channel 2, when the SP is maximum, the margin shall be 2.7V±3.3V(testing machine set on -47dBm,
1K 30%)
HI－CUT function：choose channel 2, when the SP is maximum, turn on HI-CUT function, the SP output shall reduce
0.4V-0.7V(testing machine set on -113dBm, 1K 30%)
Note: turn off Hi-cut function after this testing.
ANL function：choose channel 2, when the SP is maximum, turn off ANL function, the SP output shall increase by
0.8V-1.2V(testing machine set on -113dBm, 1K 30%)
Note: turn on ANL function after this testing.
RF GAIN function：Choose channel 2，RF GAIN adjust to minimum， SIDN shall between 8-16dB
（testing machine set on ：-60dBm 1K 30%）
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
FM mode：
FM sensitivity：choose channel 2, SP output margin between 2- 3V，the SIND on channel 1、2、3shall >11dB
（testing machine set on：-119dBm 1K 1.2K）。
SP maximum output margin：choose channel2, when the SP is maximum, the margin shall be 4.7V±5.3V, current < 0.8A,
then adjust SP to 2- 3V, the SIND shall > 33dB,SNR>35dB (testing machine set on -47dBm, 1K 1.2k)
AF sensitivity：choose channel 2, when the SP is maximum, the margin shall between 3.0-3.6V(testing machine set on
-47dBm, 1K 0.4K)
ASQ adjust：enter testing mode，choose AQ ON open on just -113dBm，choose AQ OFF turn off just on -116dBm
ASQ testing：时 Enter function menu to turn on ASQ function, the SQ shall open on -113±3dBm on channel 1,2,3 and SQ off
on -119dBm. Turn of ASQ function after this testing.
CTCSS/DCS testing：In FM mode，cut OP1、OP2 point ，and install optional CTC board，testing the working of CTCSS、
DCS decode（testing for first sample only）
。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。 End 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
