Power supply voltage In USB modeswitch the power to maximum, adjust W13, until voltage in T9 is 12V±0.1V
Quiescent currentIn USB mode switch the power to maximumMIC Short-circuited.
A J3 with Short-circuit jumperJ4 withouthold PTT, adjust W8 until the current is minimum, adjust
W8 anti direction until the current is 100MA over the minimum value.
B J4 with Short-circuit jumperJ3 without), hold PTT, adjust W9 until the current is minimum, adjust
W9 anti direction until the current is 100MA over the minimum value.
C J3, J4 all without Short-circuit jumperhold PTT, adjust W7 until the current is minimum, adjust W7
anti direction until the current is 100MA over the minimum value.
D Testing the transistor follow above order.
E 4 transistors must be installed under same voltage
Coil adjustmentBefore adjust powerL20L16 move to corresponding position as the sampleinstall J3J4 jumper
Transmit intermediate-frequency transformer adjustment Choose channel3 FM modeoutput power to maximumadjust
T13T14to get maximum output power
NoteAfter finish above alignment, be sure to install the shield over the T13T14 to ensure rest alignment.
FM mode testing
Coil adjustmentBefore adjust powerL20L16 move to corresponding position as the sampleinstall J3J4 jumper
Transmit intermediate-frequency transformer adjustment Choose channel 3 FM modeoutput power to maximum
adjust T13T14to get maximum output power, NoteAfter finish above alignment, be sure to install
the shield over the T13T14 to ensure rest alignment.
FM High powerChoose channel 2,adjust output power to maximum, adjust W14 to get power 50W±2W, the power on
channel 1 and channel 3 shall > 40w, current < 10A, frequency 50HZ
FM low powerChoose channel 123adjust output power to minimumthe power shall between 0.5-3Wcurrent <2.7A
FM maximum deviationChoose channel 2send 2K30 mV signal to MICMIC GAIN adjust to maximum, then adjust W500
to get frequency deviation between 3.5±0.2KHZthe deviation on channel 13 shall between 3-4.0 KHZ.
FM transmitting background noiseChoose channel 123adjust output power to maximumMIC short-circuitedthe
background noise shall < 50HZ
Power RSSI meterChoose channel 2 1-2 bar for minimum power Display 40-60 for 50W
SWR Choose channel 2, output power to maximumadjust TC1 to get 2 bar for SWRreverse adjust to get just one bar
SensitivityChoose channel 2send 1K signal to MICadjust machine output when the frequency deviation is 1.5Kthe
audio output of testing machines shall between 5-9mV SIND >40dB
SNRChoose channel 2send 1K signal to MICadjust machine output . when the frequency deviation is 1.5k SNR >40dB
Pre-emphasisChoose channel 2, send 1K signal to MICadjust testing machine output, when frequency deviation is 0.8K
fix this deviation point as 0 dB pointchange modulation and testing:
0.3K-11~-9 0.5K-6~-4 1.5K1~4 2K3~5 2.50K2~4 3K-1~1 4K-12-~9 5K-20~-16
FM signalingEnter test modechoose CTC/DCS channel MIC short circuitedpress PTTadjust frequency knobadjust
CTC deviation to 0.35Kwhen testing CTCSS 时,the decode frequency for the testing machine shall be ±0.5Hz
of the radio channel. DCS deviation adjust to 0.45Kwith smoothing Waveform symmetry. When testing DCS
the decode signaling for the resting machine shall be same as the radio channel.
Transmitting RBChoose channel 2adjust output power to maximumsend 1KHZ2S signalto check if the deviation is
between 2.3-2.5kfrequency 1KHZ±10HZ.
ECHOMON testingChoose channel 2open ECHO functionadjust VOL, DEL, MON to maximumHold PTTyou shall hear
your own voice from the speakeradjust MONthe voice will changewhen adjust MON to the let end
MON is offyou will not able to hear your own voice from the speaker.
SWR testingChoose channel 2adjust output power to maximumconnect 2 Parallel load of 50R to the antenna connector
SWR display ±2 bar when it is on 2.
AM mode testing
