Features
C
B
A
A Indicator Light – Provides status
information for the battery pack. The
light will illuminate in a steady state for
10 seconds when the battery pack is
expended.
B Battery Latch – Retains the battery
pack in the handpiece.
C Battery Contacts – Interlock with the
handpiece to complete the electric
circuit.
Definitions
The symbols located on the equipment and/
or labeling are defined in this section or in
the Symbol Definition Chart. See the Symbol
Definition Chart supplied with the equipment.
SYMBOL DEFINITION
General warning sign
Battery pack status
(indicator light)
WARNING
ADVERTISSEMENT
WARNING: Battery
contains Lithium-ion
material. Risk of fire,
burns, and explosion.
DO NOT short circuit,
open, crush or incinerate.
Sterilize only per
instructions. Consult
instructions for use.
