6 www.stryker.com
EN 8215-001-700 Rev-AA
Specifications
CAUTION: ALWAYS store the equipment within the specified environmental condition values throughout its
useful life.
Model: System 8 Battery Pack, Small
(REF 8212-000-000)
System 8 Battery Pack, Large
(REF 8215-000-000)
Type: Rechargeable, Lithium-Ion Battery Pack
Dimensions: 58 mm [2.3 inch] height
71 mm [2.8 inch] width
84 mm [3.3 inch] length
76 mm [3.0 inch] height
71 mm [2.8 inch] width
84 mm [3.3 inch] length
Mass: 0.27 kg [0.60 lb] 0.42 kg [0.93 lb]
Voltage: 9.9 V (Direct current) 9.9 V
Energy: 10.9 Wh 21.8 Wh
Capacity: 1100 mAh 2200 mAh
Current: 30 A (Limited) 60 A (Limited)
Cell Designation: 3IFpR19/66 3IFpR19/66-2
Mode of Operation: See the instructions for use supplied with the handpiece.
Ingress Protection: IPX0
Environmental Conditions: See the instructions for use supplied with the handpiece.
