AUDIO AND CV INPUTS (QUICK REFERENCE)
JACK NAME
LEFT IN / RIGHT IN
LEFT OUT / RIGHT OUT
INFINITE
IN GATE
IN GATE (Karplus-Strong)
FAVORITE
SHIMMER
INTERVAL
HIGH DAMP
GLIMMER
LFO CLK IN
SPEED
DEPTH
EXT LFO IN
TAP/TRIG
TAP/TRIG (Karplus-Strong)
ECHO ON
FEEDBACK
CLEAR
DECAY
WET
SIZE/PITCH
SIZE/PITCH (Karplus-Strong)
DESCRIPTION
Left and Right audio inputs. Use LEFT IN for mono input.
Left and Right audio outputs. Use LEFT OUT for mono output.
Engages the infinite effect to hold the input signal going into the reverb. Rising edge trigger will toggle the
state. Can be set to momentary response by pressing and holding HIGH BAND button at power-up. Set to
latching response by default.
Gates the input to the reverb when CV is high. Blue INPUT GAIN LED indicates audio input is gated and not
sent to the reverb. Can be set to latching response by pressing and holding REGEN button at power-up. Set
to momentary response by default.
Continuously excites or ‘bows’ the string in latching or momentary operation. See complete manual for
in-depth detail.
Toggles between the physical knob/switch settings of the module and the selected Favorite preset setting
on rising edge.
Sets shimmer gain. Knob position acts as an offset.
Sets pitch interval for shimmer. Quantized to 1/2 steps over +/- 1 octave range.
Affects the wet signal high end filtering. Positive voltage opens filter. Knob position acts as an offset.
Sets glimmer gain. Knob position acts as offset.
Sets the LFO speed to sync with phase-alignment to the clock input. SPEED knob acts as clock div/mult.
Sets LFO speed. Knob position acts as offset.
Sets LFO depth. Knob position acts as offset.
External LFO input. DEPTH knob acts as attenuverter.
Sets the delay time with clock CV input. DELAY/TUNE knob acts as clock mult/div. Clock min 25ms, clock max 3s.
Triggers or ‘plucks’ the string on rising edge transition.
Busses the delay output to the WET output to mix with the reverb signal.
Affects delay feedback or Karplus-Strong string decay/resonance. Knob position acts as offset.
Clears audio data from reverb buffer when rising edge detected.
Affects reverb decay length. Knob position acts as offset.
Affects wet output signal level. Knob position acts as offset.
1V/octave 0V = No size/pitch change. -2V = 2 octaves down. +2V = 2 octaves up. SIZE/PITCH knob acts as offset.
Tunes string to a range of 4 octaves over 4V at 1V/octave. DELAY/TUNE knob acts as fine tune control over
1 octave range.
VOLTAGE RANGE
+/-10V (20Vpp)
+/-10V (20Vpp)
0-5V
0-5V
0-5V
0-5V
+/-5V
+/-5V
+/-5V
+/-5V
Rising edge triggered
+/-5V
+/-5V
+/-5V
Rising edge triggered
Rising edge triggered
0-5V
+/-5V
Rising edge triggered
+/-5V
+/-5V
+/-2V
0-4V
