Stuart Turner Mainsboost Plus - Checklist for Vertical Installation; Vertical System Components List

- 4 -
Cont ...
CHECKLIST
Item Description Qty Item Description Qty
Package
1
1 ¼ “ BSP pressure gauge 2
Package
2
1 Mainsboost vessel 1
2 Lever isolating ball valve 1
Package
3
1 Pump 1
3
Pressure vessel connector
fitting
1 2 Manifold Assy 1
4
6 bar pressure regulating
valve
1 3 Pressure relief valve 1
5 ¼ x ½ “ BSP Brass bush 1 4 Hose 2
6 Y pattern inline strainer 1 5 Sealing washer 2
7 Double check valve 1 6
Pump mounting bolt
assy
1 set
8 1¼ “ BSP Pressure gauge 1
Your product may vary slightly from the picture above.
Mainsboost Plus (Vertical)
IMPORTANT: Your Mainsboost Plus water performance system will be delivered
in a minimum of three boxes on one pallet. Please check the contents within
24 hours of receipt and if any component is damaged, please contact Stuart
Turner Ltd immediately.
Package 2
Mainsboost vessel
Fig. 3
1
Package 1
Upstream line-in kit
Fig. 1
6
1
4
8
5
2
7
3
Package 3
MJ3 pump
Fig. 2
5
4
2
1
3
6
