5 CONFIGURATION
5.11 Mainsboost Plus is a very flexible solution, offering a patent protected packaged
system to suit any type or size of building no matter how large or small the
demand is. The following illustrations depict just some of the most typical
installations.
5.12 Single occupancy application:
Use of Mainsboost Plus in a
house offers water on
demand whilst giving
maximum flexibility. As can
be seen the upstream
line-in kit has to be fitted on to
the rising main but the vessel/
pump can be fitted wherever
there is a space, for example;
utility, kitchen, upstairs
cupboard or loft, providing
adequate provisions are taken
for the weight, frost protection
etc (see Fig 9).
Where height restrictions exist
the MPB 200SH and
MBP 250SH litre Mainsboost
Plus can be supplied for
horizontal installation.
5.13 Multiple occupancy application:
Often affected by poor water
supplies Mainsboost Plus
offers the perfect solution.
For multiple occupancy
buildings again the
upstream line-in kit is located
next to the rising main and
sized to meet the demand of
the entire building. Each
apartment then has its own
vessel and pump located
within the property, sized to
meet the apartments own
demand (see Fig. 10).
Fig. 9
Fig. 10
