Screen Status Indicators
SCREEN OPERATION
Status Indicator
8
Status
Indicator
Descripon Soluon
OVERTEMP
Unit Has Exceeded
Temperature Threshold
Unit needs to cool down before more welds can be
made. Please allow the unit to cool down and clear
the overtemp warning.
UNDER
VOLTAGE
Insucient Input
Power
Unit has detected insucient supply power. Connect
the unit to a more stable power supply.
DC LIMIT ON
Duty Cycle Limiter
Acvated
Protects capacitor from overheang by liming the
user to a maximum average duty cycle. This protec-
on only acvates when the set point of the welder
is above 85V. Below 85V there is no limitaon to the
duty cycle of the unit.
ERR: CHRG TIME
Max Charge Time
Exceeded
Unit has taken too long to charge and there may be an
issue with the capacitor. With unit powered down en-
sure that all connectors and connecons are ght.
ERR: OUTPUT
Capacitor Short
Detecon
Capacitor is not charging properly and the outputs
may be shorted. Check the unit for damage as well as
