Connecng the Welding Leads
1. Connect the stud gun weld cable into the gun terminal socket on the front of the welding unit. The
cable end plug has a flat which aligns with a dot on the panel mount socket. Secure the connector
into the panel mount socket, and then turn it clockwise until it locks into proper position. Failure
to properly make these connections could result in damage to the connectors.
2. Connect the weld gun control cable into the center socket connector. The control cable plug has a
large pin and a small pin that match the socket on the unit. Push the plug firmly into the socket
and twist clockwise to secure the plug into the correct position.
3. Connect the ground clamp into the ground terminal socket on the front of the unit, this connec-
tion is identical to step 1.
Connecng the Ground Clamp
1. Prior to securing the clamp, make certain that
the contact area is free of rust, paint, grease, or
any other impuries to ensure a good ground
connecon.
2. Aach the clamp of the welding ground lead to
the work piece.
3. Most applicaons will require only one ground
clamp, but certain applicaons will require an
addional dual clamp.
SETUP AND WELDING
9
Stud Gun Weld
Cable Connecon
Ground Cable Connecon
Stud Gun Control
Cable Connecon
