MIDI EDT PAGE #1
MIDI EDT PAGE #1MIDI EDT PAGE #1
MIDI EDT PAGE #1
This page displays and selects assignments to Mod wheel, After touch, Continuous
Controller 1, and Continuous Controller 2.
Functions that can be controlled via MIDI:
LFO 1 (depth of Lfo 1) PW3 (pulse width of Osc 3) ENV 3 (env. 3 amount)
LFO 2 (depth of Lfo 2) VCF (filter cutoff frequency) ENV 4 (env. 4 amount)
LFO 3 (depth of Lfo 3) RESO (filter resonance) ENV 1 (env. 1 amount)
OSC 2 (freq of Osc 2) MIX 2 (level of Osc 2) LFO 1 (lfo 1 rate)
OSC 3 (freq of Osc 3) MIX 3 (level of Osc 3) LFO 2 (lfo 2 rate)
PW1 (pulse width of Osc 1) MIXR (level of Ringmod) LFO 3 (lfo 3 rate)
PW2 (pulse width of Osc 2) MIX N (level of Noise)
The range of each controller can be scaled from 0% (no effect) to 99% (full effect).
Controller 1 and Controller 2 can be assigned to receive any of the 128 possible MIDI
controllers, with these exceptions:
CON #1 Reserved for Mod wheel CON #64 Reserved for Sustain pedal
CON #5 Reserved for Glide time CON #65 Reserved for Glide on/off
CON #7 Reserved for Main volume CON #121-127 Reserved for mode messages
Note: MIDI controllers add data to the function selected from what is set up in the
patch. Only one MIDI controller at a time can be assigned to any one destination.
MIDI EDIT PAGE #2
MIDI EDIT PAGE #2MIDI EDIT PAGE #2
MIDI EDIT PAGE #2
CHANNEL: Selects reception channel 1 - 16.
MEM PROTECT: ON1 - no saving can be done. ON2 - no saving can be done and
front panel pots are disabled. OFF - memory protect off.
SYSX:SEND PROGRAM
SELECT, SAVE - SEND: Initiates System Exclusive functions. Select an individual
program or entire memory (ALL), then press SAVE.
BEND PAGE
BEND PAGEBEND PAGE
BEND PAGE
PITCH: Sets bend range from 0 to one octave in semitone increments.
CUTOFF: Assigns bender to control filter frequency in semitone increments.
TRANSPOSE: Overall pitch transposition. HIGH is up one octave, MED is normal
LOW is down one octave.
6
