Setup parameters
To enter in Zone Edit, press the IN button when one of the
Zones is selected; you can still select another Zone by using
the left/right Encoder’s controls. From the list of parameters,
you can either press IN, rotate the Encoder or move the cursor
to the right to enable the parameter‘s modication.
Zone Edit
Page 1
ENABLE
to enable or disable the selected zone
MIDI PORT
to select the related OUT port within the
avaible ones (USB, MIDI 1, MIDI 2)
CHANNEL
001 - 016
PROGRAM
001 - 128
MSB - LSB
000 - 127 (for both)
Page 2
VOLUME
000 - 127
KEY RANGE 
A0 - C8
VELOCITY RANGE 
000 - 127
VELOCITY CURVE 
SOFT/NORMAL/HARD, USER(1-6),
FIXED (VALUE 001-127)
AFTERTOUCH
OFF/ON
Page 3
TRANSPOSE 
-12 / +12 SEMITONES
OCTAVE
-3 / +3
PEDAL 1
(selectable functions)
PEDAL 2
(selectable functions)
PEDAL 3
(selectable functions)
Page 4
PEDAL 4*
(special functions)
STICK 1 X
(selectable functions)
STICK 1 Y
(selectable functions)
STICK 2 X
(selectable functions)
STICK 2 Y
(selectable functions)
Page 5
STICK 3 X
(selectable functions)
STICK 3 Y
(selectable functions)
INSTRUMENT NAME
SOUND NAME
SL 88 STUDIO
KEYRANGE:
SL 88 STUDIO
 KEY RANGE
SL 88 STUDIO
 VELOCITY RANGE
SL 88 STUDIO
 VELOCITY CURVE
SL 88 STUDIO
 TRANSPOSE
*Pedal 4 can be programmed to control all available parame-
ters (switch and continuous) but it can also be set to be con-
nected with special multi-pedals (SLP3-D, NTP, etc.) allowing
to have up to three pedals in one plug. A typical application
is a triple piano pedal, where two pedals can control the Soft
and Sostenuto functions, while the third pedal can control a
half-pedaling Damper function.
