(© Oct, 2007)
Compact CW Series Installation, Operation & Maintenance Manual
ir Technology Systems, Inc.
APPENDIX A - FORMS
Stulz Air Technology Systems Inc.
Frederick, Maryland USA 21704
Telephone: (301) 620-2033 Facsimile: (301) 620-1396
Checklist for Completed Installation
Frederick, Maryland USA 21704
Telephone: (301) 620-2033
Facsimile: (301) 620-1396
ir Technology Systems, Inc.
❏
1 Proper clearances for service access have
been maintained around equipment.
❏
2 Equipment is level and mounting fasteners (if
applicable) are tight.
❏
3 Piping completed to refrigerant or coolant loop
(if required).
❏
4 All field installed piping leak tested.
❏
5 Refrigerant charge added (if required).
❏
6 Condensate pump installed (if required).
❏
7 Condensate drain line connected and trap is
filled with water.
❏
8 Water supply line connected to humidifier
(if required).
❏
9 Safety pan installed under ceiling mounted
equipment (if required).
❏
10 Filter box installed (if required).
❏
11 Filter (s) installed (if required).
❏
12 Ductwork completed or optional plenum
installed (if required).
❏
13 Incoming line voltage matches equipment
nominal nameplated rating ± tolerances.
❏ 14 Main power wiring connections to the
equipment, including earth ground, have been
properly installed.
❏ 15 Customer supplied main power circuit breaker
(HACR type) or fuses have proper ratings for
equipment installed.
❏ 16 All wiring connections are tight.
❏ 17 Control wiring connections completed to
optional equipment and devices including wiring
to a wall mounted control panel (if required).
❏ 18 Foreign materials have been removed from
inside and around all equipment installed
(shipping materials, construction materials,
tools, etc.).
❏ 19 Inspect all piping connections for leaks during
initial operation.
A-1
