Assembly Instructions
Step 2
Step 2
Step 1
Hardware Used
Step 1
Place the Table Top Assembly (B) upside
down on a soft, level surface, place the
Leg With Door Magnet (D) on the left side
of the control panel, and attach it to the
table top assembly (B) with (4)
M6 x 14 bolt (AA) as illustrated.
Note: Leg installing has the directions
requirement. Make sure the leg of no
screw hole side is facing outward when
install the leg 2 (D).
Attach (3) Leg (C) to the Table Top
Assembly (B) with (12) M6 x 14 bolt (AA)
as illustrated.
Note: Leg installing has the directions
requirement. Make sure the leg of no
screw hole side is facing outward when
install the Leg (C).
M6x14 4 pcs
Hardware Used
M6x14 12 pcs
To Next Page
