Suaoki G500 - Operation Guidance; Charging Methods

充电控制器
- Solar Charger Controller
逆变器
-Inverter
小功率家电照明
-Small Household Appliances (Low Power)
电池系统
-Battery System
照明车载冰箱
-Car Refrigerator
12V/6A, 12.6V/10A
5V/USB
手机充电
-Cell Phone Charging
Operation Guidance
Attention:
1. Installation environment should meet our requirements.
2. Make sure that the air inlet/outlet of this product is not blocked.
■
How to charge this product
Charge with Solar Charging Cable
1. Place your solar panel (We recommend Suaoki 50W/100W Semi Flexible Solar Module)
where it can get as much direct sunlight as possible.
2. Connect the solar panel by solar charging cable, then insert the Anderson plug of the cable
into the solar charging port. You can know the charging state from the LCD display.
4. It is capable of taking in 150W of solar charging power. The open-circuit voltage of the
solar panel should be from 14V
（
15
？）
to 40V.
5. With the built-in advance system control circuit module, it will stop being charged when
the battery is fully powered.
Note:
Check to make sure that you have connected the solar charging cable correctly. Red terminal
of solar charging cable for positive battery terminal. Black terminal of solar charging cable
for negative battery terminal.
You cannot charge this product using solar charging cable and adapter at the same time.
Charge with Adapter
Plug the adapter into wall outlet, then attach the other side to the input port of the portable
power supply, you can know the charging state from the LCD display. It will take around 8 to
10 hours to charge the portable power supply with the adapter. With the built-in advance
system control circuit module, it will stop being charged when the battery is fully powered.
The adapter comes in two pieces. Connect the two pieces by plugging the cable into the box.
Note: You cannot charge this product using solar charger and adapter at the same time.
Charge with Car Charger
It’s a good choice to charge it when you drive all the way. Plug one end of the car charger to
