Suaoki PF3S Series - Height Measurement; Speed Measurement

4.Speed Measurement
※ Note: Angle α must be less than 10°. The smaller the angle α, the higher the
accuracy.
Short press to switch to the speed measuring mode. Hold“ ”and keep aiming at
the target object as it moves. The speed of the movement can be measured and
displayed.
*Speed measurement range: 18~300km/h
3.Height Measurement
Short press to switch to height measurement mode. In this mode, would be
displayed on screen. Aim at the target and press to measure straight-line distance to
the target, height and angle α.
M
M
EN-6
Straight-line distance
Straight-line distance
Height
Angle
