Planning Information
Wine Storage Model 424
Dimensions in parentheses are in
millimeters unless otherwise specified.
9
1" (
25)
DOOR FRAME PROFILE
1" (
25)
2
1
/4" (57) Rail/ Stile
Glass
C
L
Cabinet Door
Profile
WINE STORAGE DOOR FRAME
FULL-SCALE TEMPLATE
The full-scale illustr
ations on this page and the following
pages enable you to understand some of the unique situa-
tions you may face as you design the Wine Storage units
into homes. These templates can be easily photocopied or
used in y
our tr
acings.
IMPORTANT NOTE: Rails and stiles must be a minimum
of
2
1
/4" (57) wide
. The bac
k sides of r
ails and stiles that
will be visible thr
ough the glass door will need to be
finished.
The full-scale illustration above shows a
cr
oss-section of the Model 424 door
frame profile.
