Sub-Zero 427 Specifications

Planning Information
Wine Storage Model 427
10
Installation of a Model 427 within framed
cabinetry.
*Dimensions ma
y v
ary
.
Dimensions in parentheses are in
millimeters unless otherwise specified.
A) ALL REVEALS ARE 1/8" (3)
B
) BOTTOM RAIL MUST BE REMOVABLE
*DIMENSIONS MAY VARY
B
A
TOP VIEW
A A
D
OOR PANEL
C
ABINET DOOR
T
O WALL
S
UB-ZERO
UNIT
PANEL WIDTH
1
1
/2"
(38)
1
1
/2"
(38)
76
3
/4"
(1949)
FRONT VIEW SIDE VIEW
26
3
/4" (679)
84"
(2624)
1
1
/2"
(38)
1
1
/2"
(38)
4"*
(102)
4" (102)
80"*
(2032)
24"
(610)
27"
(686)
SHADED AREA
INDICATES STATIONARY
STYLES AND RAILS
27"
(
686)
2
4"
(
610)
The illustration shows a Model 427 installed within a
framed cabinetry beaded inset application.
IMPORTANT NOTE: Dimensions are based on a
1
/8" (3)
reveal. A reveal of up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted accordingly.
FRAMED CABINETRY – BEADED INSET APPLICATION

Sub-Zero 427 Specifications

General

Brand	Sub-Zero
Model	427
Category	Wine Cooler
Language	English
