Sub-Zero 427 - Wine Shelf Wood Facing

Planning Information
Wine Storage Model 427
Dimensions in parentheses are in
millimeters unless otherwise specified.
14
20
1
5
/16" (532)
WIDTH
Maximum Thickness
FRONT VIEW
SIDE VIEW
1
1
/2" (
38)
5
/8"
(
16)
7
/64"
(3)
5
/6
4
"
(
2)
2
3
/64"
(9)
9
/1
6
" (
14)
27
/32"
(
21)
WINE SHELF WOOD FACING
FULL-SCALE TEMPLATE
Use the full-scale illustration above as a template if you
choose to replace the natural cherry wood facing with
wood more complementary to your design and surround-
ing cabinetry.
