Sub-Zero 427 - Frameless Cabinetry Applications; Frameless Cabinetry

Planning Information
Wine Storage Model 427
11
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(610)
PANEL WIDTH
75
7
/8"
(1927)
2
6
3
/4"
*
(679)
4"*
(102)
80"*
(2032)
27"
(686)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
FRAMELESS CABINETRY APPLICATIONS
The illustration below shows a hypothetical installation
of a Model 427 within frameless cabinetry. Review the
illustration, giving particular attention to the overall panel
specifications. Also refer to the full-scale illustrations at
the end of this section for specifics on door openings.
I
MPORTANT NOTE:
D
imensions are based on a
1
/8"
(3)
reveal. A reveal of up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted accordingly.
FRAMELESS CABINETRY
Installation of a Model 427 within
frameless cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
