Sub-Zero 427R Planning Information

Planning Information
Wine Storage Model 427R
Dimensions in parentheses are in
millimeters unless otherwise specified.
15
FRAMED CABINETRY
IMPORTANT NOTE: The depth of the Model 427R
is 24" (610) from the front of the unit to its back.
Your design may necessitate moving the unit back,
or cabinets forward to achieve a flush fit.
Door closed – full scale (top view) *If the panel is thicker than
3
/4" (19), it is recommended that you
utilize the built-in 90˚ door stop to prevent damage to the panel
and face fr
ame
.
1
8
3
4
MIN.
(3)
PANEL
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
LINE OF INTERFERENCE*
AT MAXIMUM DOOR OPENING
MOUNTING BRACKET SCREW
(19)
FLUSH
FURNITURE
FINISH
LINE OF INTERFERENCE*
TO BACK
OF UNIT
24
(610)
SUB-ZERO DOOR
REVEAL
T
25
7
8
(657)
DOOR WIDTH
24
(610)
LINE OF INTERFERENCE*
S
UB-ZERO
DOOR
TO BACK
OF UNIT
2
105˚ maximum door opening –
1
/4 scale (top view)

Sub-Zero 427R Specifications

General

Brand	Sub-Zero
Model	427R
Category	Wine Cooler
Language	English
