Sub-Zero 427R Planning Information

Planning Information
Wine Storage Model 427R
Dimensions in parentheses are in
millimeters unless otherwise specified.
16
FRAMELESS CABINETRY
IMPORTANT NOTE: The depth of the Model 427R
is 24" (610) from the front of the unit to its back.
Your design may necessitate moving the unit back,
or cabinets forward to achieve a flush fit.
Door closed – full scale (top view) *If the panel is thicker than
3
/4" (19), it is recommended that you
utilize the built-in 90˚ door stop to prevent damage to the panel
and face fr
ame
.
1
8
MIN.
(3)
REVEAL
3
4
PANEL
LINE OF INTERFERENCE*
AT MAXIMUM DOOR OPENING
MOUNTING BRACKET SCREW
(19)
TO BACK
OF UNIT
24
(610)
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
LINE OF INTERFERENCE*
SUB-ZERO DOOR
25
7
8
(657)
DOOR WIDTH
1
05˚ maximum door opening –
1
/4 s
cale (top view)
TO
WALL
24
(610)
LINE OF INTERFERENCE*
SUB-ZERO DOOR
3
/4" (19) DOOR PANEL
S
IDE PANEL
COUNTERTOP
