Planning Information
Wine Storage Model 430
Dimensions in parentheses are in
millimeters unless otherwise specified.
11
HARDWARE CONSIDERATIONS
With the Model 430 (overlay), you must supply your own
handle hardware. It is recommended that you use our
optional handles and use the pre-drilled holes supplied to
locate the handles within the frame of our unit. The metal
frame on the door has numerous mounting holes on each
side to accommodate Sub-Zero accessory handles. This
will allow you to provide the best possible handle align-
ment and not take away from the strength of the stile in
this area after the unit is used a number of times. We
recommend using a pull handle and not a pull knob.
If you elect to place different hardware on these units, we
encourage you to fasten the hardware by passing through
our door and attach the hardware through the Sub-Zero
door's frame.
Optional stainless steel handles are available in a variety of
diameters and lengths in the classic, platinum and carbon
stainless steel finishes and polished chrome. Contact
your Sub-Zero dealer for specifics. To obtain local dealer
information, visit the Locator section of our website,
subzero.com.
W OOD FA CING – WINE SHELVES
Sub-Zero has provided a natural cherry wood facing to
each of its wine shelves in each model. If, however, you
would like to replace these strips with wood more comple-
mentary to your design and surrounding cabinetry, you
can.
The Wine Shelf Wood Facing Dimensions illustration, on
page 13, can be used as a full-scale template. You must
follow the la
yout of this format to accommodate the
shelves properly. To remove the cherry strips, take the
shelves out and merely remove the screws. Reverse the
pr
ocedure to affix the new wood
.
If you choose to stain or seal the wood facing, be aware
that some of these substances are hazardous and will
damage stored wine.
When planning for hardware,
please refer to the Door Frame
Profile full-scale illustration on
the following page to give you a
better understanding of the
unit's frame and positioning of
the glass for the door. You must
not drill through the glass.
