Planning Information
Wine Storage Model 430
Dimensions in parentheses are in
millimeters unless otherwise specified.
6
W
W
H
H
Framed Door and Grille Panels
INTEGRATING CABINETRY
Unless you are installing a stainless steel unit, you will
need to provide a door panel frame for the glass door. If
you order a stainless steel unit, the Model 430 will be
shipped with panels and hardware installed and you will
m
erely install the Sub-Zero.
FRAMED PANELS
Refer to page 7 for detailed information on integrating
cabinetry for the framed panel application.
An 11" (279) louvered grille is standard on framed applica-
tions. Optional louvered grilles are available in 1" (25)
height increments from 10" (254) to 15" (381).
You may choose to use Sub-Zero's optional panel grille for
the Model 430 framed application. Optional panel grilles
are available in 1" (25) height increments from 10" (254) to
15" (381). See chart below for panel dimensions.
FRAMED PANEL DIMENSIONS
WIDTH HEIGHT
Door Panel 28
1
/8" (714) 67
11
/1
6
" (1719)
Width of Rails and Stiles 2
1
/4" (57) min
Door Panel Weight Limit 25 lbs (11 kg)
Panel Thickness
5
/8" (16) min
FRAMED
GRILLE
P ANEL DIMENSIONS
WIDTH
HEIGHT
10" (254) Grille 28
3
/16" (716) 8
15
/16" (227)
11" (279) Grille 28
3
/16" (716) 9
15
/16" (252)
12" (305) Grille 28
3
/16" (716) 10
15
/16" (278)
13"
(330) Grille
28
3
/16" (716) 11
15
/16" (303)
14" (356) Grille 28
3
/16" (716) 12
15
/16" (329)
15" (381) Grille 28
3
/16" (716) 13
15
/16" (354)
