Installation
Check List
For adjustment, use a
%”
allen
wrench to loosen
screws (Models
5ll
and 550
exc/uded).
This allows the
door to move left to right or
in and out.
Once the adjustments are
made be sure to tighten the
allen
screws tightly.
~FOOUVOE
Norma/
door
swing is 130 degrees, except
for Mode/s
511
and 550. An
optional 90 degree door stop
is available.)
It is recommended after
going through the installation
procedure that you anchor
the unit to the opening. See
Figures
31
and 32. Your
Sub-Zero product distributor
has an anchoring kit (part
#4-20-090-0)
for your use.
-1
Do not drill through model
and serial number tag.
Figure 3
1
Figure 32
.
The importance of the
installation of your Sub-Zero
cannot be overemphasized.
The proper installation of
your unit is the responsi-
bility of the selling dealer
or installer. The following
check list should be com-
pleted by the installer to
insure no part of the instal-
lation has been overlooked.
Any questions or problems
pertaining to the installation
should be directed to the
selling dealer.
l
Is
unit operating? If not,
is unit plugged in? Is
refrigerator/freezer control
on?
Cl Is packing material re-
moved? (Page 13)
Cl Is water supply line con-
nected to compression
fitting? (Page 15)
Disconnect power to unit
before checking wiring
connections.
0
Is unit leveled properly
on a solid floor? (Page 15)
Cl Is blocking necessary?
(Page 14)
III
Is drain pan installed
properly?
Cl Is toe plate installed?
(Page 15)
0
Is grille screw back in
position? (Page 14)
l Are panels installed
correctly? (Pages
16-
18)
El
Are doors adjusted?
(Pages 18 and 19)
0
Does the customer un-
derstand the unit’s opera-
tion?
Cl Is the
icemaker
switch
turned on? (Models 590,
561 and 532).
Give the customer the
warranty packet.
Product information
-
(Your Local Product
Distributor or Sub-Zero)
1~800-200-7820
Product Service
-
1-800-222-7820
