Sub-Zero’s integrated design,
beauty and quality is evident
in all of these features that
are standard on Sub-Zero’s
seven full-size units.
l Built-in Design. All
Sub-Zeros are only 24” deep.
They accept decorative door
and side panels (50 lb. weight
limit per door panel), to match
virtually any cabinetry. The
perimeter thickness cannot
exceed
%?
See pages 12 and
13 for details.
l Colored Panels. Optional
steel door and side panels
are available from our factory
in three colors: almond,
stainless steel and white.
(Model 590 offers your
choice of seven complemen-
tary colored glasswells and
ten optional color handle
inset trim panels at no cost.
The standard colored
glasswell is pewter gray and
handle inset trim panel is
pin-striped pewter gray.)
l Satin Trim. Door screws
are hidden on these units
so you have a clean look.
l Door Handles. All units
have our low-profile door
handles as a standard
feature. A D-style handle is
an option on Models 50
lR,
5OlF,
511
and 550. An
extended full-length handle is
also offered as an option on
all models. Refer to Figure A,
Page
1OA
for panel sizing
information.
l Grilles. Sub-Zero’s 11”
louvered grille is standard
on all models with the excep-
tion of the Model 590. An
optional easy-access panel
grille that accepts decorative
panel inserts is also avail-
able. In either instance, you
can order them in one inch
increments from 10” to
15’:
(Model 590 has
the
EA
panel
gt-i//e
s~andarci.)
l Toe Plate. Adjustable,
solid toe plate meets the
standards of the American
Institute of Architects. Inset
area is 4” high by 3”deep.
l Adjustable Shelves.
Cantilever glass shelves in
the refrigerator, wire shelves
in the freezer and all of the
door shelves are adjustable.
l Crispers. Each crisper has
its own humidity control and
moves easily on our roller
track system.
l Ice Maker. Each Sub-Zero
freezer offers an automatic
ice maker providing
crescent-
shaped ice.
l Utility Basket. Smaller
items are stored in the
refrigerator’s adjustable
utility basket.
l Dairy
&
Egg Modules.
Two dairy compartments
have full magnetic seal to
maintain freshness. A port-
able egg tray offers handy
storage and is removable.
l Diffused Lighting.
Sub-Zero’s overhead lighting
floods both the refrigerator
and freezer compartments
with even light.
l Dual Compressors.
Two compressors in all our
combination refrigerator/
freezer units deliver precise,
and independent tempera-
ture in the section it controls.
l Automatic Defrost.
Sub-Zero refrigerator and
freezer units have an auto-
matic defrost system.
l Front Venting. All
Sub-Zero units are front
vented so you can plan for
a truly built-in refrigerator.
l Door Swing. You can
choose left or right door
swing on our single door
units as well as our
over-and-
under models. This option
must be ordered when request-
ing the unit. You cannot
reverse the door in the field.
l Magnetic Door Gasket.
Our positive sealing gasket
ensures a tight closing door.
l Roller Base. Patented
roller base assembly allows
for easy installation.
l Door Stop Kit. For instal-
lation where the door swing
must be limited to 90 degrees,
an optional Door Stop Kit is
available.
(Norma/
door swing
is
130 degrees
wjth
the
excep-
tion of
the
550
and
511.)
