TECHNICAL DATA
5-8
MODEL 561
Prior To Serial # M/P1198140/P1213190
Refrigerator Freezer
Charge (R-12 Refrigerant)
Prior to #M/P965470 and from
#M/P965869 to #M/P1004775 7.0 oz. 8.0 oz.
From #M/P965470to #M/P965869
and from #M/P1004775 to
#M/P1198140/P1213190 8.0 oz. 9.5 oz.
Control (normal #5 setting)
Service Part No. 4201260 3012742
- Cut-in/Cut-out 39.0°/31.0° F -1.5°/-8.5° F
Compressor
Service Part No. 4201670 4201400
Mfg. Part No. EM30SC D120
Service Compressor Amps 0.8 1.4
Service Compressor BTU’s 318 762
Suction Pressure (PSIG)
- Cut-in/Cut-out 36 / 16 15 / 4
Original Defrost Timer (Cycle)
Prior to #M/P816264
Interval ---- 12 Hour
Continuous
Duration ---- 15 Minutes
From#M/P816264 to #M/P965470 and
from #M/P965869 to #M/P1004775
Interval ---- 12 Hour
(comp. run)
Duration ---- 15 Minutes
From#M/P965470 to M/P965869
and from #M/P965869 to
#M/P1198140/P1213190
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
Starting with #M1184540/P1200040
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
MODEL 561
Starting with Serial # M/P1198140/P1213190
Refrigerator Freezer
Charge (R-134a Refrigerant)
7.0 oz. 7.0 oz.
Control (normal #5 setting)
Service Part No. 4201260 3012742
- Cut-in/Cut-out 39.0°/31.0° F -1.5°/-8.5° F
Compressor
Service Part No. 4201880 4202250
Mfg. Part No. EMI30HER DA73
Service Compressor Amps 0.9 1.4
Service Compressor BTU’s 280 860
Suction Pressure (PSIG)
- Cut-in/Cut-out 35 / 9 8 / -1" Vac
Original Defrost Timer (Cycle)
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
