Cleaning Combination Units
Models 611, 611G, 650,
650G, 642, 632, 680 and 690
It is possible to turn off one
section of your combination unit
for an extended period without
disrupting the other. First, turn the
unit off, then push and hold the
warmer key of the zone you want
to disable. Then, turn the unit
back on by depressing the
ON/OFF key. The disabled zone
will be indicated with "--" in the
display. Repeat the process to turn
the zone back on. See Electronic
Control System, page 13.
Cleaning the Ice Chute
Models 680 and 690
Ice crescents may occasionally
become lodged in the ice chute
of the Model 680 or 690. The ice
chute is a clear plastic housing
that directs ice from the freezer
ice bucket to the door ice
dispenser. To remove these
obstructions, first remove the
screw in the lower left corner of
the side panel, then hold the
bottom of the side panel and
push rearward, then pull out.
Once the panel is removed, the
ice chute will be visible.
To remove the side cover of the
ice chute, press the two side
locking tabs, then pull up and
out. To reinstall, make sure the
bottom section of the ice chute is
installed first. Then fit the
outside front cover lip inside the
stationary portion. Finally, push
the two assemblies together and
close the self-locking tabs.
22
aring for your sub-Zero
C
aring for
your sub-Zero
Locking
Ta b
Models 680 & 690 ice chute
The 601RG stainless grille is
removed in a similar fashion as
the panel grille noted here.
To remove a panel grille, lift up,
then pull out at the bottom and
down to release from its
mounting bracket.
CAUTION
Failure to clean the condenser
could result in temperature
loss or mechanical failure
or damage.
Grille Springs
Louvered grille removal
Models 601R, 601RG & 601F
(framed and overlay) grille removal
1
1
2
2
3
3
Panel grille removal
