16
36"
(914)
42"
(1067)
48"
(1219)
42"
(1067)
48"
(1219)
24"
(610)
84"
(2134)
83
3
/4" (2127)
ROUGH OPENING
HEIGHT TO
FINISHED
FLOORING WITH
STANDARD
11" (279) GRILLE
83" (2108)
MIN HEIGHT
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
75
1
/2"
(1918)
7"
(178)
6"
(152)
A
ROUGH OPENING WIDTH
24"
(610)
ROUGH
OPENING
DEPTH
E
3"
(76)
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
6"
(152)
SHUT-OFF
VALVE
FRONT VIEW
TOP VIEW
EXTEND
WATER LINE
APPROX 36" (914)
FROM BACK WALL
INSTALLATION SPECIFICATIONS
Side-by-Side Models
Model 661
A) Rough Opening Width 35
1
/2" (902)
B) Min Door Clearance 20
3
/4" (527)
Model 642
A) Rough Opening Width 41
1
/2" (1054)
B) Min Door Clearance 25
5
/16" (649)
Model 685
A) Rough Opening Width 41
1
/2" (1054)
B) Min Door Clearance 25
5
/16" (649)
Model 632
A) Rough Opening Width 47
1
/2" (1207)
B) Min Door Clearance 29
1
/4" (743)
Model 695
A) Rough Opening Width 47
1
/2" (1207)
B) Min Door Clearance 29
1
/4" (743)
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
OVERALL DIMENSIONS
Side-by-Side Models
SIDE-BY-SIDE
Model 661
Model 642
Model 685
Ice | Water Dispensing
Model 632
Model 695
Ice | Water Dispensing
B
23
7
/8"
(606)
BEHIND
FRAME
3
/8"(10)
FRAME
EXTENSION
90˚
Model 661
Width 36" (914)
Height 84" (2138)
Depth 24" (610)
Model 642
Width 42" (1067)
Height 84" (2138)
Depth 24" (610)
Model 685
Ice | Water Dispensing
Width 42" (1067)
Height 84" (2138)
Depth 24" (610)
Model 632
Width 48" (1219)
Height 84" (2138)
Depth 24" (610)
Illustrations shown in stainless steel design.
Model 695
Ice | Water Dispensing
Width 48" (1219)
Height 84" (2138)
Depth 24" (610)
INSTALLATION
Refer to the
installation instruc-
tions shipped with
each Sub-Zero
product for detailed
specifications.
