Sub-Zero 632 Installation Guide

5
600
SERIES
PRE-INSTALLATION SPECIFICATIONS
Finished Rough Minimum Door
Opening Width (A) Clearance (B)
Model 611 29
1
/ 2 "(749) 30
1
/ 8 "(765)
Model 611G 29
1
/ 2 "(749) 30
1
/ 8 "(765)
Model 650 35
1
/ 2 "(902) 36
1
/ 16 "(916)
Model 650G 35
1
/ 2 "(902) 36
1
/ 16 "(916)
Model 561 35
1
/ 2 "(902) 20
3
/ 4 "(527)
Model 661 35
1
/ 2 "(902) 20
3
/ 4 "(527)
Model 642 41
1
/ 2 "(1054) 25
9
/ 16 "(649)
Model 680 41
1
/ 2 "(1054) 25
9
/ 16 "(649)
Model 685 41
1
/ 2 "(1054) 25
9
/ 16 "(649)
Model 632 47
1
/ 2 "(1207) 29
1
/ 4 "(743)
Model 690 47
1
/ 2 "(1207) 29
1
/ 4 "(743)
Model 695 47
1
/ 2 "(1207) 29
1
/ 4 "(743)
NOTE: Dimensions in parentheses are in millimeters.
83
3
/4"
(2127)
ROUGH
OPENING
HEIGHT
WITH
STANDARD
11" (279)
GRILLE
82
7
/8"
(2105)
MINIMUM
HEIGHT
REQUIRED
(LEVELERS IN)
75
1
/2"
(1918)
7"
(178)
6"
(152)
A
ROUGH OPENING WIDTH
24"
(610)
ROUGH
OPENING
DEPTH
E
3"
(76)
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
6"
(152)
SHUT-OFF
VALVE
EXTEND WATER LINE
APPROX. 36" (914)
FROM BACK WALL
FRONT VIEW
TOP VIEW
B
23
7
/8"
(606)
BEHIND
FRAME
3
/8"(10)
FRAME
EXTENSION
90˚
B
23
7
/8"
(606)
BEHIND
FRAME
3
/8"(10)
FRAME
EXTENSION
90˚
Models 601R, 601RG, 601F,
611, 611G, 650 and 650G
Models 561, 661, 642, 680, 685,
632, 690 and 695
MODELS 611, 611G, 650, 650G, 561,
661, 642, 680, 685, 632, 690 AND 695
MINIMUM DOOR CLEARANCE AT 90˚
