Sub-Zero 695

Planning Information
Built-In Model 695
Dimensions in parentheses are in
millimeters unless otherwise specified.
7
W
H
WW
H
Framed Door Panels
Framed Grille Panel
FRAMED PANELS
For framed models, the refrigerator door panel must
include a cut-out to accommodate the glasswell and bezel.
The thickness of the panel in this area can range from
1
/4"
(6) to a maximum of 1
1
/8" (29). If the panel is thicker,
p
rovisions must be made to rout out a space to accommo-
date the decorative bezel surrounding the glasswell.
An 11" (279) louvered grille is standard on framed applica-
tions. Optional louvered grilles are available in 1" (25)
height increments from 10" (254) to 15" (381).
You may choose to use Sub-Zero's optional panel grille for
the framed application. Optional panel grilles are available
in 1" (25) height increments fr
om 10" (254) to 15" (381).
Refer to the chart below for panel dimensions.
FRAMED P ANEL DIMENSIONS
WIDTH HEIGHT
Refrigerator Door Panel 27
11
/16" (703) 67
11
/16" (1719)
Freezer Door Panel 17
15
/16" (456) 67
11
/16" (1719)
Maximum Weight (per panel) 50 lbs (23 kg)
Glasswell Cut-Out Location A – 1
9
/16" (39)
(refrigerator door panel) B – 28
9
/16" (726)
FRAMED GRILLE PANEL DIMENSIONS
WIDTH HEIGHT
10" (254) Grille 46
3
/16" (1173) 8
15
/16" (227)
11" (279) Grille 46
3
/16" (1173) 9
15
/16" (252)
12" (305) Grille 46
3
/16" (1173) 10
15
/16" (278)
13" (330) Grille 46
3
/16" (1173) 11
15
/16" (303)
14" (356) Grille 46
3
/16" (1173) 12
15
/16" (329)
15" (381) Grille 46
3
/16" (1173) 13
15
/16" (354)
B
A
12
7
/16"
(315)
5
7
/8"
(150)
1
/4" (6) min
FLAT L ANDING
AREA FOR BEZEL
Glasswell Cut-Out Location
(refrigerator door panel)
IMPORTANT NOTE: Panel thickness in
the glass
well area can range from
1
/4" (6)
to a maximum of 1
1
/8" (29). If the panel is
thicker, you must rout out a minimum
1
/4"
(6) flat landing area to accommodate the
bezel surr
ounding the glass
well.
