Framed cabinet applications present you with different

questions to address. Take the time to review the specifics

of these illustrations as they will help form the basis for

your design.

These are not meant to be the only alternatives, but are sug-

gestions from designers around the country.

Reveals between cabinets and the Sub-Zero 700 Series

units are 1/4-inch in all instances and drawer and door pan-

els can vary based on information we supplied on earlier

pages.

Study these illustrations in detail.Rest assured the Sub-Zero

units are compatible with framed cabinet installations.

IMPORTANT NOTE: Refer to the full-scale illustrations at

the end of this section for specifics on panels and door

openings.

SUB-ZERO

UNIT

DOOR PANEL

CABINET

DOOR

CABINET

FRAME

DOOR PANEL

CABINET

DOOR

CABINET

FRAME

DOOR PANEL

CABINET

DOOR

CABINET

FRAME

SUB-ZERO

UNIT

SUB-ZERO

UNIT

FRAMED CABINETRY – COMMON APPLICATIONS

(TOP VIEWS)

A-ALL REVEALS ARE 1/8 INCH (3MM)

(686)

TO WALL

(610)

(686)

TO WALL

(610)

(686)

TO WALL

(610)

TRADITIONAL FRAME – FULL OVERLAY

TRADITIONAL FRAME – STANDARD OVERLAY

TRADITIONAL FRAME – 3/8" OFFSET

CAUTION

As the reveal between cabinets and the 700 Series unit

decreases, the potential exists for severe finger pinch-

ing or crushing if a hand or fingers are placed in the

opening when the door is closing.

CAUTION

When 5/8-inch or larger panels are used and a reveal

less than 1/4-inch is maintained, the door panels may

cause damage to the Sub-Zero unit when the door is

open at the maximum 105˚ stop. You should use the

built-in 90˚ stop to prevent damage.

SPECIAL NOTE: In an installation where you are plac-

ing two 700 Series tall units next to one another and

providing a minimum 1/8-inch reveal, refer to illustra-

tion 8, you cannot assume the panel width is 26

inches as shown on the top.The panels will need to be

/4 inches to ensure a consistent reveal.

FRAMED CABINET APPLICATIONS

Illus. 7

700

SERIES

Sub-Zero 700 Series
