Planning Information
Integrated Model 700TC(I)
Installation of an Integr
ated 27" (686)
wide tall unit within frameless cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
9
A
A
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(610)
PANEL WIDTH
45
3
/8"
(
1153)
26
3
/4"* (679)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
80"*
(2032)
34
1
/2"
(876)
*
27"
(686)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
FRAMELESS CABINETRY APPLICATIONS
The illustration below shows a hypothetical installation of
an Integrated 27" (686) wide tall unit within frameless
cabinetry. Review the illustration, giving particular attention
to the overall panel specifications. Also refer to the full-
scale illustrations at the end of this section for specifics
on door openings.
IMPORTANT NOTE: Dimensions are based on a
1
/8" (3)
reveal. A reveal of up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted accordingly.
FRAMELESS CABINETRY
