Planning Information
Model 700TF(I)
Dimensions in parentheses are in
millimeters unless otherwise specified.
9
A
A
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(
610)
PANEL WIDTH
45
3
/8"
(
1153)
26
3
/4"* (
679)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
80"*
(2032)
34
1
/2"
(876)
*
27"
(686)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
FRAMELESS CABINETRY APPLICATIONS
The illustration below shows a hypothetical installation of
a Integrated tall unit within frameless cabinetry. Review the
illustration, giving particular attention to the overall panel
specifications. Also refer to the full-scale illustrations at
the end of this section for specifics on door openings.
I
MPORTANT NOTE:
D
imensions are based on a
1
/8"
(3)
reveal. A reveal of up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted accordingly.
Installation of an Integrated tall unit within
frameless cabinetry.
*Dimensions ma
y v
ary.
FRAMELESS CABINETRY
