Overlay | Flush Inset Panels
FULL-SCALE TEMPLATE
Overlay and ush inset panels must be a minimum of
5
/8"
(16)
thick to support mounting the handle. Panel thickness
does not include backer and spacer panel. Mount handle
close to the opening edge of the door.
BUILT-IN REFRIGERATION
Overlay and ush inset panel thickness.
1
/4" (6) BACKER PANEL
DOOR
DEPTH OF TUBULAR
AND PRO HANDLES
1"
(25)
3"
(76)
1
1
/4" (32) PANEL
1" (25) PANEL
3
/4" (19) PANEL
2"
(51)
.10" (3) SPACER PANEL
BUILT-IN PRO 48 INTEGRATED WINE UNDERCOUNTER
