UNDERCOUNTER REFRIGERATION
WOOD FACING WIDTH
W
UC-24BG 19
1
/2" (495)
UC-24C(I) 19
1
/2" (495)
Sub-Zero, Sub-Zero & Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service
marks of Sub-Zero, Inc. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc.
All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.
Wine Rack Wood Facing
FULL-SCALE TEMPLATE
The natural cherrywood facing on wine storage racks can
be stained and sealed, or replaced with wood more comple-
mentary to surrounding cabinetry. Refer to the full-scale
template below for prole dimensions of the wood facing
and the chart for widths.
Wine rack wood facing prole.
1
1
/2"
(38)
27
/32"
(21)
7
/
64
"
(3)
23
/64"
(9)
23
/64"
(9)
1
/2"
(13)
27
/32"
(21)
1
/4"
(6)
5
/8"
(16)
9
/16"
(14)
5
/64"
(2)
5
/64"
(2)
9
/16"
(14)
7
/64"
(3)
424G, UW-24,
424FSG, UW-24FS, WS-30
IW
-18, IW-24,
IW
-30, IW-30R
7
/32" (6)
UNDERCOUNTER WINE INTEGRATED PRO 48 BUILT-IN
