50 | English
WINE STORAGE
Opening Dimensions
MODEL ICBWS-30 STANDARD INSTALLATION
OPENING WIDTH
MODEL W
ICBWS-30 749 mm
If a 2108 mm grille height is specied, the opening height
must be decreased by 22 mm. If a 2235 mm grille height is
specied, the opening height must be increased by 102 mm.
If two units are installed side by side, refer to page 52 for
dual standard installations.
762 mm
2134
mm
102 mm
1873
mm
606
mm
796
mm
432
mm
606 mm
60 mm
HEIGHT DIMENSIONS ± 13 mm
665 mm
Overall Dimensions
MODEL ICBWS-30
SPECIFICATIONS
STORAGE CAPACITY BOTTLES (750 ML)
ICBWS-30 147
Overall dimensions are based on the stainless steel model.
For ush inset applications, add 13 mm to door clearance
dimensions.
2127 mm
OPENING
HEIGHT
610 mm
OPENING
DEPTH
NOTE: Shaded line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
W
OPENING WIDTH
WINE INTEGRATED PRO 48 BUILT-IN
