Page #3 background imageLoading...
Page #3 background image
P5 To change Use UP/DOWN keys to set
the P5 desired value. In time it may be
parameter, possible that the display may
press the be offset by a degree or so.
SET key To compensate for this error,
you may need to add or minus
the degrees required to achieve
the correct temperature.
Setting value is from -
0 0
10.0 C to + 10.0 C
Example: The temperature on
0
the display is 28.0 C, whereas
0
the actual temperature is 30.0 C.
You will need to set the P5 mode
0
to 2.0 C, which means that once
out of the programming mode,
that once out of the programming
mode, the temperature will show
0 0 0
30.0 C (28.0 C + 2.0 C).
6 P6 parameter Function: To set time delay
between compressor relay
restart time.
P6 To change Use UP/DOWN keys to set
the P6 desired value. This parameter is
parameter, used to protect the compressor
press the from restarting in a short period
SET key. of time and can be set between
0 to 20 minutes.
Example: If this parameter is
set at 3 minutes, the relay will
cut off at the set temperature, but
will cut off at the set temperature,
but will not restart for a minimum
of 3 minutes, even if the
differential is achieved earlier.
This parameter is good to protect
the life of the compressor or
even in applications where the
probe is placed at places where
there are sudden & short in
temperature like above a cold
room door.
20 Min
0 Min
3 Min
4
(High Temp) indicating that the
temperature has gone above the
value in this parameter and at
this point the buzzer will come on.
4 P4 parameter Function : To set the comp.
differential (hysterisis).
P4 To change Use UP/DOWN keys to set
the P4 desired value. Differential
parameter, between cutout and cutin
press the temperature can be set
0 0
SET key. between 0.1 C to 20.0 C
Example: If the set point is set
0
at 10.0 C and differential is
0
set at 2.0 C, then when the
0
system reaches 10.0 C, the
comp. relay will cutout. Since
0
the differential is 2.0 C, the comp.
0
Relay will cutin at 12.0 C.
0 0
(10.0 C + 2.0 C)
5 P5 parameter Function : To set probe 1
offset (cold room temp.)
calibration.
3 P3 parameter Function: To set minimum
allowable Low temperature limit.
P3 To change Use UP/DOWN keys to set
the P3 desired value. Once set at a will
parameter, particular value, this not allow
press the the set point to go below this
SET key value and above P2 setting.
Example: Setting this parameter
0
at -30.0 C will not allow the set
0
point to go below -30.0 C. Also,
if the temperature reaches
0
-30.0 C, the display will show
Lt(Low Temp) indicating that the
temperature has gone below
the value in this parameter and
at this point the buzzer will
come on.
XX
0
-40.0 C
0
-40.0 C
20.0
0
C
0
0.1 C
0
2.0 C
0
10.0 C
0
-10.0 C
0
0.0 C
3
XX = Set point
L
(Message on Display)
