5-2
#7012423 - Revision A - August, 2009
Component Access / Removal
Model UC-15I (Undercounter Ice Machine)
COMPONENT ACCESS AND REMOVAL
This section explains how to access and remove model UC-15I cosmetic, mechanical and sealed system compo-
nents. An attempt has been made to arrange these procedures in such a way as to simulate which components
would need to be removed first in order to gain access to other components. When following a component removal
procedure, it may be necessary to reference another component removal procedure listed earlier in this section.
This section is arranged as follows:
Page:
• Exterior Components ........................................................................................................................................... 5-3
• Components Below Top Cover (Excluding Sealed System Components) .......................................................... 5-8
• Interior Components ........................................................................................................................................... 5-10
• Compressor / Condenser Area Components ..................................................................................................... 5-12
• Sealed System Components .................................................................................................................... 5-15
NOTE: Before continuing, please take note of the WARNINGS and CAUTIONS below.
TO AVOID ELECTRIC SHOCK, POWER TO THE UNIT MUST BE DISCONNECTED WHENEVER ACCESSING
AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR OTHER ELEC-
TRICAL COMPONENTS.
• If removing or disconnecting door hinge assemblies, remember they are spring loaded and may recoil
quickly when released.
• If working in the compressor area, remember that compressor and tubing may be hot.
• If working on or around the condenser, remember that condenser fins and fan blade are sharp.
To Next Page
