Sub-Zero UC-15I

1-5
#7012423 - Revision A - August, 2009
Model UC-15I (Undercounter Ice Machine)
General Information
C
ontrol
Panel
Water
Water
Water
Shutters
Reservoir
Large Capacity
Ice
Bin Storage
Filter
Kickplate
Rating
Plate
Bin
Light
Gasket
Ice
Scoop
Reversible
Door Hinge
COMPONENTS / FEATURES
MODEL DESCRIPTION
Models UC-15I and UC-15IO have a gravity drain, while Models UC-15IP and UC-15IPO have a built-in pump to
allow greater installation flexibility.
Model Features
• 24" (610 mm) depth design for a complete integrated look.
• Door accepts custom panels.
• Automatic ice machine provides high-quality, clear ice.
• Ice storage bin capacity of up to 25 lbs (11 kg).
• Automatic defrost.
• Reversible door swing.
• Front venting with removable kickplate allows unit to be serviced from the front.
• Solid core door with gasket and door closer.
• UL approved for US and Canada, with the UC-15IO and UC-15IPO being UL approved for outdoor use.
