General Information
Model UC-15I (Undercounter Ice Machine)
Serial Number Tag Information:
WARRANTY INFORMATION
This page contains summaries of the 2, 5 & 12 Year
Warranties that are supplied with Sub-Zero Appliances.
TWO, FIVE & TWELVE YEAR Warranty Summary
• Two year TOTAL PRODUCT warranty, *parts and
labor.
• Five Year SEALED SYSTEM warranty, **parts and
labor.
• Sixth through Twelfth year LIMITED SEALED SYS-
TEM warranty, sealed system **parts only.
ONE & FIVE YEAR Non-Residential Warranty
Summary (Outdoor Models ONLY)
• One Year TOTAL PRODUCT warranty, *parts and
labor.
• Five year LIMITED SEALED SYSTEM warranty,
sealed system **parts only.
ONE & FIVE YEAR Display / Model Home Warranty
Summary (Display units sold three years after date
of manufacture)
• One Year TOTAL PRODUCT warranty, *parts and
labor.
• Five year LIMITED SEALED SYSTEM warranty,
sealed system **parts only.
Warranty Details:
* Total Product Parts include, but is not limited to:
Control, Circulating Pump, Switches, Fan Motor &
Blade, Drain Tube, Wiring, Water Valve, Hot Gas
Valve, Door hinges, Compressor Electricals, etc. . .
NOTE: The ice machine must be protected if it will
be subjected to ambient temperatures below 32°F
(0°C). Component failure caused by exposure to
freezing temperatures is not covered by the warranty.
** Sealed System Parts include the following:
Compressor, Condenser, Evaporator, Filter-Drier,
Heat-exchanger, All Tubing That Carries the Freon.
NOTE: Condenser Fan Motor, Freon, Solder and
compressor electricals are NOT
considered sealed
system parts.
General Warranty Notes:
• Sub-Zero, Inc. assumes no liability or responsibility
for Sub-Zero products that have been altered in any
way, including the use of parts and/or components not
specifically approved by Sub-Zero.
• All warranties begin at the time of the unit's initial
installation.
• The serial tag is located in two places: one on the left
wall of the ice bin and one on the back of the unit.
(See Diagram below). Please have this information
whenever contacting the factory or parts distributor.
MODEL UC15IO SERIAL NO. XXXXXXX
MFG DT 0809
DESIGN PRESSURE HIGH SIDE 350 P. S. I. G.
DESIGN PRESSURE LOW SIDE 250 P. S. I. G.
REFRIG. TYPE R-134A REFRIG. CHARGE 5.6OZ.
VOLTS 115V CYCLE 60 Hz PHASE 1
TOTAL AMPS 4.1 A
URC
DPMCRE2
SUBZERO FREEZER CO. INC.
