Sub-Zero UC-15I - Technical Data

Minimum - Maximum Water Pressure 20 - 80 psi (1.4 - 5.5 bar)
7-2
#7012423 - Revision A - August, 2009
Technical Data
Model UC-15I (Undercounter Ice Machine)
Minimum - Maximum Water Temperature 35 - 90°F (1.6 - 32.2°C)
Liquid Line Thermistor Resistance (Ohms) at 32°F (0°C) / 77°F (25°C) 30K-33K / 8K-12K
Bin Thermostat Cut In / Cut Out 40°F(4.5°C) / 34°F(1.0°C)
Total Unit Amperage 4.1
Refrigerant Charge (134a) 5.6 oz. (1.5 kg)
Technical Data
