COMPONENT INFORMATION
2-3
Figure 2-5. Refrigerator Doors
Model 532, 542, 561
Gasket
Handle Assy.
Dairy Assy.
Door Shelf
Assy.
Figure 2-7. Refrigerator Door
Model 590
Gasket
Handle Assy.
Dairy Assy.
Door Shelf Assy.
Not Shown:
• Trim Panels
• Dispenser Assy.
Figure 2-4. Freezer Doors
Model 532, 542, 561
Gasket
Handle Assy.
Shelf Assy.
Figure 2-6. Freezer Door
Model 590
Gasket
Handle Assy.
Door Shelf Assy.
Not Shown:
• Trim Panel
