Sub-Zero Wolf ICB700 Series

Page 40
5-3
Airflow & Fan Blade Spacing
7011902 - Revision A - October, 2009
International Integrated
International Integrated
(ICB700 Base)
(ICB700 Base)
Series
Series
Figure 5-3. ICB700BF/I Airflow and Fan Blade Spacing
Blade
Bracket
Clamp
Back
EVAPORATOR
FAN BLADE HUB
TO FAN BRACKET
SPACING
17.64 mm ± 1.59 mm
(11/16'' ± 1/16'')
