7-2
Component Access/Removal
7011902 - Revision A - October, 2009
International Integrated
International Integrated
(ICB700 Base)
(ICB700 Base)
Series
Series
COMPONENT ACCESS AND REMOVAL
This section explains how to adjust, access and/or remove ICB700 Series base unit components. If different models
have similar procedures, they are grouped together under the appropriate heading. The units covered in the proce-
dures are listed between brackets after the heading.
This section is arranged as follows:
.............................................................................................................. Page:
Exterior Cosmetic / Mechanical Components ........................................................................................................................ 7-3
Interior Cosmetic / Mechanical Components ........................................................................................................................ 7-5
Compressor Area Mechanical Components ........................................................................................................................ 7-15
Sealed System Components.................................................................................................................................................. 7-20
An attempt has been made to arrange these procedures in such a way as to simulate which components would
need to be removed first in order to gain access to other components. When following a component removal proce-
dure, it may be necessary to reference another component removal procedure listed earlier in this section.
NOTE: Before continuing, take note of the WARNINGS and CAUTIONS below.
IF IT IS NECESSARY TO REMOVE A UNIT FROM ITS INSTALLATION, REMEMBER THAT THE UNIT COULD
TIP FORWARD WHEN PULLED FORWARD BEYOND THE ANTI-TIP COMPONENTS, RESULTING IN SERI-
OUS INJURY OR DEATH. PULLING A UNIT FROM ITS INSTALLATION SHOULD ONLY BE PERFORMED BY
A QUALIFIED AND AUTHORIZED SERVICE TECHNICIAN OR INSTALLER.
TO AVOID ELECTRIC SHOCK, POWER TO THE UNIT MUST BE DISCONNECTED WHENEVER ACCESSING
AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR OTHER ELEC-
TRICAL COMPONENTS. IF THE UNIT IS PLUGGED IN, BUT HAS NOT BEEN SWITCHED ON BY PRESSING
THE UNIT ON/OFF KEY, AC LINE VOLTAGE IS STILL PRESENT AT THE MAIN CONTROL BOARD.
IF REMOVING A DRAWER REMEMBER THAT DRAWERS ARE HEAVY. IF THEY WERE TO FALL, THEY
COULD CAUSE SERIOUS PERSONAL INJURY.
If working in the compressor area, remember that the compressor and tubing may be hot.
If working on or around the evaporator or condenser, remember that evaporator and condenser fins are
sharp.
